Product main technical specifications:
| Specifications | C6136FC6236F | C6140FC6240F | C6150FC6250F | |
| Max. swing over bed | 360mm | 400mm | 500mm | |
| Max. swing over cross slide | 190mm | 230mm | 330mm | |
| Max. swing over gap | 520mm | 560mm | 660mm | |
| Center Distance | 750/1000/1500mm | |||
| Bed Width | 360mm | |||
| Spindle hole | 52mm | |||
| Spindle nose | C6 | |||
| Spindle taper | MT6 | |||
| Spindle speed | 16-1600rpm(12steps ) | |||
| Metric threads range | 0.25-7mm(17 kinds) | |||
| Inch threads range | 5-144/inch(30 kinds) | |||
| Moudle threads range | 0.25-3.5mm(12 kinds) | |||
| Cross slide travel | 180mm | 222mm | ||
| Compound rest travel | 95mm | |||
| Cross-section size of toolshank | 20x20 | |||
| Taper of tailstock sleeve | MT4 | |||
| Dia. of tailstock sleeve | 65mm | |||
| Travel of tailstock sleeve | 140mm | |||
| Main drive motor | 4kw | 5.5kw | ||
| Packing size (LxWxH) | 750mm | 2220x1150x1590mm | ||
| 1000mm | 2470x1150x1590mm | |||
| 1500mm | 2970x1150x1590mm | |||
| Net weight/Gross weight(kg) | 750mm | 1350/2000kg | 1400/2050kg | 1500/2150kg |
| 1000mm | 1450/2100kg | 1500/2150kg | 1600/2250kg | |
| 1500mm | 1600/2250kg | 1650/2300kg | 1750/2400kg | |
| Standard accessories |
| 3 jaw chuck |
| Center ¢er sleeve |
| Wrenches |
| Oil gun |
| Operation manual |
| Optional accessories |
| Steady rest |
| Follow rest |
| 4 jaw chuck |
| Face plate |
